| Physical specs | |
|---|---|
| Width | 432 mm |
| Depth | 501 mm |
| Height | 1154 mm |
| Housing material | 9-ply, 15mm Plywood, Internally Braced, with Texured Paint |
| Colour | Melns |
| Weight | 40.7 Kg |
| Audio specs | |
| Power | 600/2400W Peak |
| Coverage (Horz. x Vert.) | 90° x 50° |
| Max. sound pressure level | 137dB |
| Frequency range | 62-18,000 Hz (-3dB), 38-20,000 Hz (-10dB) |
| Transducers | LF EVS-15K 380 mm (15”), HF DH-1K 39 mm (1'') titanium compression driver |
| Input impedance | 4 Ω |
| Crossover frequency | Recommended High-Pass Frequency 35Hz Internal crossover YES 1.7kHz |
| Connections | |
| Signal connectors | Parallel Neutrik Speakon NL4 |
