| Physical specs | |
|---|---|
| Width | 432 mm |
| Depth | 429 mm |
| Height | 685 mm |
| Housing material | 15 mm plywood with EVCoat |
| Colour | Melns |
| Weight | 23.2 kg |
| Audio specs | |
| Power | 400 W continuous, 1600 W peak |
| Coverage (Horz. x Vert.) | 90° x 60° |
| Max. sound pressure level | 132 dB |
| Frequency range | 75-18,000 Hz (-3dB), 50-20,000 Hz (-10dB), Rec. High-Pass Frequency 50 Hz |
| Transducers | LF EVS-15M 381 mm (15”), HF DH-1M 1'' titanium compression driver |
| Input impedance | 8 Ω |
| Crossover frequency | 1.6 kHz |
| Connections | |
| Signal connectors | Neutrik NL4 in/thru |
